| Common Standards & Designations | ||
| Standard | Title / Scope | Applicable Alloys / Grades |
| ASTM B103/B103M | Standard Specification for Phosphor Bronze Plate, Sheet, Strip, and Rolled Bar | C51000, C51100, C51900, C52100, C52400, C53400, C54400 |
| JIS H 3110 | Copper and Copper Alloy Sheets, Plates, and Strips | C5111, C5191, C5212 |
| JIS H 3130 | Copper and Copper Alloy Sheets and Strips for Electrical and Electronic Equipment | C5210 |
| EN 1652 | Copper and Copper Alloys – Plate, Sheet, Strip and Circles for General Purposes | CW451K, CW452K, CW453K, CW454K |
| GB/T 2059 | Copper and Copper Alloys – Strip | QSn4-0.3, QSn6.5-0.1, QSn7-0.2, QSn8-0.3 |
| AMS 4510 | Bronze Strip, Phosphor Bronze | C51000 |
| Dimensional Specifications | ||
| Phosphor Bronze Strip/Coil | ||
| Product Form | Thickness Range | Width Range |
| Strip | 0.02 – 5.0 mm | 10 – 600 mm |
| Plate | 0.5 – 50 mm | 100 – 2000 mm |
| Sheet | 0.1 – 50 mm | ≤1200 mm |
| Thickness Tolerances | ||
| Thickness Range (mm) | Tolerance (± mm) – Strip | Notes |
| 0.02 – 0.05 | 0.005 – 0.008 | Precision thin strip |
| 0.05 – 0.10 | 0.008 – 0.010 | Fine gauge |
| 0.10 – 0.30 | 0.010 – 0.015 | Standard tolerance |
| 0.30 – 1.00 | 0.015 – 0.030 | General purpose |
| 1.00 – 3.00 | 0.030 – 0.050 | Heavy gauge |
| 3.00 – 5.00 | 0.050 – 0.080 | Plate thickness |
| Applicable Standards Summary | ||
| Standard | Scope | Alloy Families Covered |
| ASTM B103/B103M | Phosphor Bronze Plate, Sheet, Strip, Rolled Bar | C51000, C51100, C51900, C52100, C52400, C53400, C54400 |
| JIS H 3110 | Copper and Copper Alloy Sheets, Plates, and Strips | C5111, C5191, C5212 |
| JIS H 3130 | Copper and Copper Alloy Sheets/Strips for Electrical/Electronic Equipment | C5210 |
| EN 1652 | Copper and Copper Alloys – Plate, Sheet, Strip | CW451K, CW452K, CW453K, CW454K |
| GB/T 2059 | Copper and Copper Alloys – Strip | QSn4-0.3, QSn6.5-0.1, QSn7-0.2, QSn8-0.3 |
| ASTM B543 | Copper-Nickel Alloys for Tubes | Cu-Ni bronze alloys |
| ISO 6892-1 | Tensile Testing Standard | Reference for mechanical testing |
